Building Elements

#

Test specimen Standard Test facility
façades (façade elements) DIN EN ISO 140-5 / 16283
DIN EN ISO 717-1

P1 façade test facility

data sheet

solid walls, roofs, hollow floor systems (horizontal) DIN EN ISO 10140-1 to 5
DIN EN ISO 717-1

P2 wall test facility

data sheet

longitudinal walls, flanking walls, ventilation channels / ducts DIN EN ISO 10848-1 and 2
DIN EN ISO 717-1

P3 diagonal test facility for walls and partitions

data sheet

windows, glazings, façade sections, wall sections DIN EN ISO 10140-1 to 5
DIN EN ISO 717-1
ASTM E 90 / 1332

P4 window test facility

data sheet

suspended ceilings DIN EN ISO 10848-1 and 2
DIN EN ISO 717-1
ASTM E 90 / 1332

P5 test facility for suspended ceilings

data sheet

lightweight partition walls,
movable partition walls
DIN EN ISO 10140-1 to 5
DIN EN ISO 717-1
ASTM E 90 / 1332

P6 wall test facility

data sheet

noise barriers DIN EN 1793-2
ZTV-Lsw 06
DB Richtlinie 804-5501

P6 wall test facility

data sheet

industrial roof,
wooden floors,
ventilation shafts
DIN EN ISO 10140-1 to 5
DIN EN ISO 717-1
ASTM E 90 / 1332

P8 ceiling test facility

data sheet

ceiling constructions
hollow floors
suspended ceilings (vertical)
DIN EN ISO 10140-1 to 5
DIN EN ISO 717-1
ASTM E 90 / 1332

P9 screed test facility

data sheet

doors, door leafs DIN EN ISO 10140

PT door test facility

data sheet



#

Test Specimen Standard Test Facility
floating screeds on concrete floor DIN EN ISO 10140-1 to 5
DIN EN ISO 717-2

P9 screed test facility

data sheet

floating screeds on wooden floor DIN EN ISO 10140-1 to 5
DIN EN ISO 717-2

P8 ceiling test facility

data sheet

ceiling constructions
hollow floors
suspended ceilings
(horizontal)
DIN EN ISO 10140-1 to 5
DIN EN ISO 717-2

P2 wall test facility

data sheet

ceiling constructions
hollow floors
suspended ceilings
(vertical)
DIN EN ISO 10140-1 to 5
DIN EN ISO 717-2

P8 ceiling test facility
data sheet

P9 screed test facility
data sheet

floor coverings
(laminate, carpet, PVC, rubber, linoleum)
DIN EN ISO 10140-1 to 5
DIN EN ISO 717-2
DIN EN ISO 16251

P8 ceiling test facility
data sheet

P9 screed test facility
data sheet

Comet

#

Test Specimen Standard Test facility
acoustic ceilings,
cooling ceilings,
wall units
DIN EN ISO 354
DIN EN ISO 11654
ASTM C 423

P20 reverberation room

data sheet

partition walls / screens DIN EN ISO 354
DIN EN ISO 11654

P20 reverberation room

data sheet

ceiling panels, acoustic panels DIN EN ISO 354
DIN EN ISO 11654

P20 reverberation room

data sheet

baffle constructions DIN EN ISO 354
DIN EN ISO 11654

P20 reverberation room

data sheet

curtains, blinds DIN EN ISO 354
DIN EN ISO 11654

P20 reverberation room

data sheet

bass absorber DIN EN ISO 354
DIN EN ISO 11654

P20 reverberation room

data sheet

noise barriers DIN EN 1793-1
ZTV-Lsw 06
DB Richtlinie 804-5501

P20 reverberation room

data sheet

#

#

Test Specimen Standard Test Facility
airborne sound insulation between rooms
DIN EN ISO 16283-1
DIN 4109
VDI 4100

impact sound insulation between rooms
DIN EN ISO 16283-2
DIN 4109
VDI 4100

airborne sound insulation of facades
DIN EN ISO 16283-3
DIN 4109, VDI 4100
ASTM E 90/ 1332

reverberation time in rooms DIN EN ISO 354
DIN EN ISO 3382
DIN 18041
