Installations

Test Specimen Standard Test Facility
wastewater installation systems,
(pipe clamps, pipe insulations, fire protection collar, etc.)
DIN EN 14366-1
(DIN 4109, VDI 4100,
SIA 181, Ö-Norm 8115-2)

P12 test facility for sanitary elements

data sheet

sanitary system measurements, exemplary installations,
(prewall installations, inwall installations, lightweight installation walls)

DIN EN 14366-1,
DIN EN ISO 10052,
(DIN 4109, VDI 4100,
SIA 181, Ö-Norm 8115-2)

P12 test facility for sanitary elements
data sheet

P10 test facility for sanitary elements for lightweight construction
data sheet

Guidelines on testing according to DIN EN 14366-1

In this download the procedure of testing the acoustic performance of wastewater systems according to DIN EN 14366-1 is described. It is particularly focused on presenting the regulations applicable for performance of the test of wastewater systems at the test laboratory of the Fraunhofer Institute for Building Physics. By introducing the "Guidelines on the testing of the acoustic performance of wastewater systems" particular attention shall be payed to ensuring a high degree of reproducibility and comparability of the measurement results of different wastewater systems, as well as the applicability of the results in practice.

PreNoise®

Would you like to know in advance how building services systems will perform acoustically in your building? Our PreNoise® web app makes this possible: it allows you to predict the noise level of building services systems in buildings based on DIN EN 12354-5. Developed by the Building acoustics Working Group, the app provides an approximation of the planned object and enables you to select suitable systems with the required sound insulation level as early as the planning phase of your project. The app also gives you an impression of how changes to the building structure can affect the noise level.

Test Speciman Standard Test Facility
shower trays, bath-tubs,
whirlpool systems
DIN 4109, VDI 4100,
DIN EN ISO 10 052,
SIA 181, Ö-Norm 8115-2

P12 test facility for sanitary elements

data sheet

floor drains, drain channels (shower channel, floor-level shower areas)
DIN 4109, VDI 4100,
DIN EN ISO 10 052,
SIA 181, Ö-Norm 8115-2

P12 test facility for sanitary elements

data sheet

prewall installations (WC- and wash basin units, etc.) DIN 4109, VDI 4100,
DIN EN ISO 10 052,
DIN EN 14 366, SIA 181,
Ö-Norm 8115-2

P12 test facility for sanitary elements
data sheet

P10 test facility for sanitary elements for lightweight construction
data sheet

sanitary system measurements, exemplary installations (prewall installations, inwall installations, lightweight installation walls) DIN 4109, VDI 4100,
DIN EN ISO 10 052,
DIN EN 14 366, SIA 181,
Ö-Norm 8115-2

P12 test facility for sanitary elements
data sheet

P10 test facility for sanitary elements for lightweight construction
data sheet

drinking water installations (pipes,  flushing systems, etc.) DIN 4109, VDI 4100,
DIN EN ISO 10 052,
DIN EN ISO 3822, SIA 181,
Ö-Norm 8115-2

P12 test facility for sanitary elements

data sheet

pipe clamps,
pipe insulations
DIN 4109, VDI 4100,
DIN EN ISO 10 052,
DIN EN ISO 3822, SIA 181,
Ö-Norm 8115-2

P12 test facility for sanitary elements

data sheet

Test Specimen Standard
Test Facility
appliances, (mixer taps, hand showers, valves, pressure reducer, etc.) water treatment plants, drinking water filters, water softening, etc.)
DIN EN ISO 3822,
DVGW W570-1, DIN 4109

P11 test facility for appliances

data sheet
